Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
Operational Amplifier
Mount Type
Surface
Package Type
SOT-23
Number of Channels
1
Pin Count
5
GBP - Gain Bandwidth Product
1.4MHz
Minimum Supply Voltage
3V
Maximum Supply Voltage
6V
Input Bias Current
150 nA
Minimum Operating Temperature
-40°C
Vos - Input Offset Voltage
3 mV
Slew Rate
0.6V/μs
Maximum Operating Temperature
125°C
Height
1.3mm
Length
3mm
Standards/Approvals
RoHS
Series
TSV321
Output Current
80mA
Automotive Standard
AEC-Q100
Input Offset Current
60 nA
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
₪ 165.00
₪ 3.30 Each (Supplied on a Reel) (ex VAT)
₪ 193.05
₪ 3.861 Each (Supplied on a Reel) (inc. VAT)
Production pack (Reel)
50
₪ 165.00
₪ 3.30 Each (Supplied on a Reel) (ex VAT)
₪ 193.05
₪ 3.861 Each (Supplied on a Reel) (inc. VAT)
Stock information temporarily unavailable.
Production pack (Reel)
50
| quantity | Unit price | Per Reel |
|---|---|---|
| 50 - 90 | ₪ 3.30 | ₪ 33.00 |
| 100 - 240 | ₪ 2.535 | ₪ 25.35 |
| 250 - 490 | ₪ 2.355 | ₪ 23.55 |
| 500+ | ₪ 2.205 | ₪ 22.05 |
