Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
MOSFET
Channel Type
Type N
Maximum Continuous Drain Current Id
4.3A
Maximum Drain Source Voltage Vds
800V
Series
MDmesh, SuperMESH
Package Type
TO-220
Mount Type
Through Hole
Pin Count
3
Maximum Drain Source Resistance Rds
2.4Ω
Channel Mode
Enhancement
Forward Voltage Vf
1.6V
Typical Gate Charge Qg @ Vgs
32.4nC
Maximum Power Dissipation Pd
30W
Minimum Operating Temperature
-55°C
Maximum Operating Temperature
150°C
Standards/Approvals
No
Length
10.4mm
Height
9.3mm
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
₪ 89.18
₪ 17.835 Each (In a Pack of 5) (ex VAT)
₪ 104.34
₪ 20.867 Each (In a Pack of 5) (inc. VAT)
Standard
5
₪ 89.18
₪ 17.835 Each (In a Pack of 5) (ex VAT)
₪ 104.34
₪ 20.867 Each (In a Pack of 5) (inc. VAT)
Stock information temporarily unavailable.
Standard
5
| quantity | Unit price | Per Pack |
|---|---|---|
| 5 - 20 | ₪ 17.835 | ₪ 89.18 |
| 25 - 45 | ₪ 14.22 | ₪ 71.10 |
| 50 - 95 | ₪ 13.065 | ₪ 65.32 |
| 100 - 245 | ₪ 11.805 | ₪ 59.02 |
| 250+ | ₪ 11.73 | ₪ 58.65 |
