Technical Documents
Specifications
Brand
Texas InstrumentsProduct Type
ESD Protection Array
Diode Configuration
Quad
Direction Type
Bi-Directional
Minimum Breakdown Voltage Vbr
5.5V
Mount Type
Surface
Package Type
USON
Maximum Reverse Stand-off Voltage Vwm
3.6V
Pin Count
10
Peak Pulse Power Dissipation Pppm
17W
ESD Protection
Yes
Clamping Voltage VC
8.8V
Minimum Operating Temperature
-40°C
Test Current It
5A
Maximum Peak Pulse Current Ippm
2A
Maximum Operating Temperature
125°C
Number of Elements per Chip
4
Standards/Approvals
No
Width
1.1mm
Height
0.5mm
Length
2.6mm
Series
TPD4E02B04
Maximum Reverse Leakage Current
10nA
Automotive Standard
AEC-Q100
Country of Origin
Thailand
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
₪ 282.60
₪ 4.71 Each (Supplied on a Reel) (ex VAT)
₪ 330.64
₪ 5.511 Each (Supplied on a Reel) (inc. VAT)
Production pack (Reel)
60
₪ 282.60
₪ 4.71 Each (Supplied on a Reel) (ex VAT)
₪ 330.64
₪ 5.511 Each (Supplied on a Reel) (inc. VAT)
Stock information temporarily unavailable.
Production pack (Reel)
60
| quantity | Unit price | Per Reel |
|---|---|---|
| 60 - 100 | ₪ 4.71 | ₪ 94.20 |
| 120 - 220 | ₪ 3.15 | ₪ 63.00 |
| 240 - 480 | ₪ 3.045 | ₪ 60.90 |
| 500+ | ₪ 2.94 | ₪ 58.80 |
