Technical Documents
Specifications
Brand
Texas InstrumentsProduct Type
Logic Gate
Logic Function
OR
Mount Type
Through Hole
Number of Elements
4
Number of Inputs per Gate
2
Schmitt Trigger Input
No
Package Type
PDIP
Pin Count
14
Logic Family
4000
Input Type
CMOS
Maximum Propagation Delay Time @ CL
90ns
Minimum Operating Temperature
-55°C
Maximum High Level Output Current
-4.2mA
Maximum Operating Temperature
125°C
Minimum Supply Voltage
3V
Height
4.57mm
Length
19.3mm
Standards/Approvals
No
Maximum Supply Voltage
18V
Maximum Low Level Output Current
4.2mA
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
₪ 97.88
₪ 3.915 Each (In a Tube of 25) (ex VAT)
₪ 114.52
₪ 4.581 Each (In a Tube of 25) (inc. VAT)
25
₪ 97.88
₪ 3.915 Each (In a Tube of 25) (ex VAT)
₪ 114.52
₪ 4.581 Each (In a Tube of 25) (inc. VAT)
Stock information temporarily unavailable.
25
| quantity | Unit price | Per Tube |
|---|---|---|
| 25 - 25 | ₪ 3.915 | ₪ 97.88 |
| 50 - 100 | ₪ 3.015 | ₪ 75.38 |
| 125 - 225 | ₪ 2.34 | ₪ 58.50 |
| 250 - 475 | ₪ 2.34 | ₪ 58.50 |
| 500+ | ₪ 2.325 | ₪ 58.12 |
