Technical Documents
Specifications
Brand
STMicroelectronicsRated Average On-State Current Irms
4A
Product Type
TRIAC
Mount Type
Surface
Package Type
TO-252
Maximum Gate Trigger Current Igt
35mA
Repetitive Peak Reverse Voltage VDRM
600V
Surge Current Rating
31A
Pin Count
3
Maximum Gate Trigger Voltage Vgt
1.3V
Configuration
Single
Maximum Holding Current Ih
35mA
Minimum Operating Temperature
-40°C
Peak Gate Power Dissipation
1W
Maximum Operating Temperature
125°C
Height
2.4mm
Length
6.6mm
Standards/Approvals
No
Repetitive Peak Off-State Current
5μA
Peak On-State Voltage
1.56V
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
₪ 20.70
₪ 2.07 Each (Supplied on a Reel) (ex VAT)
₪ 24.22
₪ 2.422 Each (Supplied on a Reel) (inc. VAT)
Production pack (Reel)
10
₪ 20.70
₪ 2.07 Each (Supplied on a Reel) (ex VAT)
₪ 24.22
₪ 2.422 Each (Supplied on a Reel) (inc. VAT)
Stock information temporarily unavailable.
Production pack (Reel)
10
