Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
TRIAC
Rated Average On-State Current Irms
16A
Mount Type
Surface
Package Type
TO-263
Maximum Gate Trigger Current Igt
50mA
Repetitive Peak Reverse Voltage VDRM
600V
Surge Current Rating
168A
Pin Count
3
Configuration
Single
Maximum Gate Trigger Voltage Vgt
1V
Maximum Holding Current Ih
75mA
Minimum Operating Temperature
-40°C
Peak Gate Power Dissipation
1W
Maximum Operating Temperature
150°C
Length
10.28mm
Standards/Approvals
No
Height
4.6mm
Repetitive Peak Off-State Current
4.1mA
Peak On-State Voltage
1.5V
Automotive Standard
No
Product Details
