Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
Diode
Mount Type
Through Hole
Package Type
TO-220
Maximum Continuous Forward Current If
8A
Peak Reverse Repetitive Voltage Vrrm
200V
Diode Configuration
Single
Series
STTH802
Rectifier Type
Switching
Pin Count
2
Peak Reverse Current Ir
6μA
Maximum Forward Voltage Vf
1.05V
Minimum Operating Temperature
-65°C
Peak Non-Repetitive Forward Surge Current Ifsm
100A
Peak Reverse Recovery Time trr
30ns
Maximum Operating Temperature
175°C
Length
10.4mm
Height
9.3mm
Standards/Approvals
RoHS
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
₪ 407.25
₪ 8.145 Each (Supplied in a Tube) (ex VAT)
₪ 476.48
₪ 9.53 Each (Supplied in a Tube) (inc. VAT)
Production pack (Tube)
50
₪ 407.25
₪ 8.145 Each (Supplied in a Tube) (ex VAT)
₪ 476.48
₪ 9.53 Each (Supplied in a Tube) (inc. VAT)
Stock information temporarily unavailable.
Production pack (Tube)
50
| quantity | Unit price | Per Tube |
|---|---|---|
| 50 - 190 | ₪ 8.145 | ₪ 81.45 |
| 200 - 490 | ₪ 7.29 | ₪ 72.90 |
| 500+ | ₪ 6.42 | ₪ 64.20 |
