Technical Documents
Specifications
Brand
STMicroelectronicsDirection Type
Uni-Directional
Diode Configuration
Array
Product Type
TVS Diode
Minimum Breakdown Voltage Vbr
23.3V
Mount Type
Surface
Package Type
QFN
Maximum Reverse Stand-off Voltage Vwm
22V
Pin Count
2
Peak Pulse Power Dissipation Pppm
1.4kW
Clamping Voltage VC
41V
ESD Protection
Yes
Minimum Operating Temperature
-55°C
Test Current It
1mA
Maximum Peak Pulse Current Ippm
35A
Maximum Operating Temperature
150°C
Number of Elements per Chip
1
Height
0.55mm
Standards/Approvals
No
Width
1mm
Length
1.6mm
Maximum Reverse Leakage Current
200nA
Automotive Standard
No
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
₪ 7,320.00
₪ 0.915 Each (On a Reel of 8000) (ex VAT)
₪ 8,564.40
₪ 1.071 Each (On a Reel of 8000) (inc. VAT)
8000
₪ 7,320.00
₪ 0.915 Each (On a Reel of 8000) (ex VAT)
₪ 8,564.40
₪ 1.071 Each (On a Reel of 8000) (inc. VAT)
Stock information temporarily unavailable.
8000
| quantity | Unit price | Per Reel |
|---|---|---|
| 8000 - 8000 | ₪ 0.915 | ₪ 7,320.00 |
| 16000+ | ₪ 0.87 | ₪ 6,960.00 |
