Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
TRIAC
Rated Average On-State Current Irms
25A
Mount Type
Through Hole
Package Type
TO-220
Maximum Gate Trigger Current Igt
50mA
Repetitive Peak Reverse Voltage VDRM
800V
Surge Current Rating
260A
Pin Count
3
Configuration
Single
Maximum Gate Trigger Voltage Vgt
1.3V
Maximum Holding Current Ih
75mA
Minimum Operating Temperature
-40°C
Peak Gate Power Dissipation
1W
Maximum Operating Temperature
125°C
Height
9.15mm
Length
10.4mm
Standards/Approvals
No
Repetitive Peak Off-State Current
5μA
Peak On-State Voltage
1.55V
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
₪ 43.26
₪ 21.63 Each (In a Pack of 2) (ex VAT)
₪ 50.61
₪ 25.307 Each (In a Pack of 2) (inc. VAT)
Standard
2
₪ 43.26
₪ 21.63 Each (In a Pack of 2) (ex VAT)
₪ 50.61
₪ 25.307 Each (In a Pack of 2) (inc. VAT)
Stock information temporarily unavailable.
Standard
2
| quantity | Unit price | Per Pack |
|---|---|---|
| 2 - 18 | ₪ 21.63 | ₪ 43.26 |
| 20 - 38 | ₪ 18.84 | ₪ 37.68 |
| 40+ | ₪ 18.165 | ₪ 36.33 |
