STMicroelectronics Panel, 3-Pin, TRIAC 800 V, Gate Trigger 1.3 V
Technical documents
Specifications
Brand
STMicroelectronicsRated Average On-State Current Irms
25A
Product Type
TRIAC
Mount Type
Panel
Package Type
RD-91
Maximum Gate Trigger Current Igt
100mA
Repetitive Peak Reverse Voltage VDRM
800V
Surge Current Rating
260A
Pin Count
3
Configuration
Single
Maximum Gate Trigger Voltage Vgt
1.3V
Maximum Holding Current Ih
80mA
Minimum Operating Temperature
-40°C
Peak Gate Power Dissipation
1W
Maximum Operating Temperature
125°C
Width
27 mm
Height
14mm
Length
40mm
Standards/Approvals
No
Repetitive Peak Off-State Current
3mA
Peak On-State Voltage
1.55V
Automotive Standard
No
Product details
TRIAC, 25A to 40A, STMicroelectronics
TRIACs, STMicroelectronics
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
₪ 186.15
₪ 93.075 Each (In a Pack of 2) (ex VAT)
₪ 217.80
₪ 108.898 Each (In a Pack of 2) (inc. VAT)
Standard
2
₪ 186.15
₪ 93.075 Each (In a Pack of 2) (ex VAT)
₪ 217.80
₪ 108.898 Each (In a Pack of 2) (inc. VAT)
Stock information temporarily unavailable.
Standard
2
| quantity | Unit price | Per Pack |
|---|---|---|
| 2 - 2 | ₪ 93.075 | ₪ 186.15 |
| 4 - 8 | ₪ 86.43 | ₪ 172.86 |
| 10 - 18 | ₪ 85.35 | ₪ 170.70 |
| 20 - 48 | ₪ 84.495 | ₪ 168.99 |
| 50+ | ₪ 83.64 | ₪ 167.28 |
