Technical Documents
Specifications
Brand
STMicroelectronicsRated Average On-State Current Irms
12A
Product Type
TRIAC
Mount Type
Through Hole
Package Type
TO-220
Maximum Gate Trigger Current Igt
10mA
Repetitive Peak Reverse Voltage VDRM
800V
Surge Current Rating
126A
Pin Count
3
Configuration
Single
Maximum Gate Trigger Voltage Vgt
1.3V
Maximum Holding Current Ih
15mA
Minimum Operating Temperature
-40°C
Peak Gate Power Dissipation
1W
Maximum Operating Temperature
125°C
Height
15.9mm
Length
10.4mm
Standards/Approvals
No
Repetitive Peak Off-State Current
5mA
Peak On-State Voltage
1.55V
Automotive Standard
No
Product Details
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
₪ 258.00
₪ 10.32 Each (Supplied in a Tube) (ex VAT)
₪ 301.86
₪ 12.074 Each (Supplied in a Tube) (inc. VAT)
Production pack (Tube)
25
₪ 258.00
₪ 10.32 Each (Supplied in a Tube) (ex VAT)
₪ 301.86
₪ 12.074 Each (Supplied in a Tube) (inc. VAT)
Stock information temporarily unavailable.
Production pack (Tube)
25
| quantity | Unit price | Per Tube |
|---|---|---|
| 25 - 45 | ₪ 10.32 | ₪ 51.60 |
| 50 - 95 | ₪ 9.93 | ₪ 49.65 |
| 100 - 245 | ₪ 8.955 | ₪ 44.78 |
| 250+ | ₪ 8.715 | ₪ 43.58 |
