Technical Documents
Specifications
Brand
STMicroelectronicsProduct Type
Bipolar Transistor
Maximum DC Collector Current Idc
-2A
Maximum Collector Emitter Voltage Vceo
-60V
Package Type
SOT-23
Mount Type
Surface
Transistor Configuration
Single
Maximum Collector Base Voltage VCBO
-60V
Maximum Power Dissipation Pd
500mW
Transistor Polarity
PNP
Minimum DC Current Gain hFE
45
Maximum Emitter Base Voltage VEBO
-5V
Minimum Operating Temperature
-65°C
Pin Count
3
Maximum Operating Temperature
150°C
Standards/Approvals
No
Length
3.04mm
Height
1.4mm
Automotive Standard
No
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
₪ 3,420.00
₪ 1.14 Each (On a Reel of 3000) (ex VAT)
₪ 4,001.40
₪ 1.334 Each (On a Reel of 3000) (inc. VAT)
3000
₪ 3,420.00
₪ 1.14 Each (On a Reel of 3000) (ex VAT)
₪ 4,001.40
₪ 1.334 Each (On a Reel of 3000) (inc. VAT)
Stock information temporarily unavailable.
3000
| quantity | Unit price | Per Reel |
|---|---|---|
| 3000 - 6000 | ₪ 1.14 | ₪ 3,420.00 |
| 9000 - 21000 | ₪ 1.065 | ₪ 3,195.00 |
| 24000+ | ₪ 1.05 | ₪ 3,150.00 |
