Samtec CLM Series Vertical Through Hole PCB Socket, 30-Contact, 2 Row, 1 mm Pitch Solder
Technical documents
Specifications
Brand
SamtecNumber of Contacts
30
Product Type
PCB Socket
Number of Rows
2
Sub Type
Board-to-Board
Pitch
1mm
Current
3.1A
Termination Type
Solder
Housing Material
Liquid Crystal Polymer
Mount Type
Through Hole
Orientation
Vertical
Connector System
Board-to-Board
Voltage
270 V
Series
CLM
Minimum Operating Temperature
-55°C
Row Pitch
1mm
Contact Plating
Gold
Maximum Operating Temperature
125°C
Contact Material
Phosphor Bronze
Standards/Approvals
No
