Samtec BCS Series Straight Through Hole PCB Socket, 8-Contact, 1 Row, 2.54 mm Pitch Solder
Technical documents
Specifications
Brand
SamtecNumber of Contacts
8
Product Type
PCB Socket
Number of Rows
1
Sub Type
Board-to-Board
Pitch
2.54mm
Current
4.6A
Housing Material
Liquid Crystal Polymer
Termination Type
Solder
Mount Type
Through Hole
Orientation
Straight
Connector System
Board-to-Board
Voltage
475 V
Series
BCS
Minimum Operating Temperature
-55°C
Maximum Operating Temperature
125°C
Contact Material
Bronze
Contact Plating
Gold
Standards/Approvals
No
Product details
Standard 2.54mm Box Connector Socket Strip - BCS Series
BCS series board to board PCB through hole mount standard box connector socket strip with a 2.54mm pitch, a single row configuration and choice of top or horizontal entry body orientation. The body of these BCS series 2.54mm PCB board-to-board box connector socket strips is made from black liquid crystal polymer and the contacts are made from phosphor bronze with a 0.25μm gold plating on the contact and matte tin on the tail. The temperature range at which these BCS board to board box connector socket strips can be used is -55 to +125°C.
Part numbers BCS-XXX-X HE are single row, horizontal entry.
Part numbers BCS-XXX-X TE are single row, top entry.
