Technical Documents
Specifications
Brand
onsemiDirection Type
Uni-Directional
Logic Family
LCX
Product Type
Voltage Level Shifter
Maximum Propagation Delay Time @ CL
7.5ns
Mount Type
Surface
Package Type
SOIC
Number of Elements per Chip
1
Output Type
TTL
Pin Count
20
Logic Function
Buffer
Maximum Low Level Output Current
24mA
Minimum Supply Voltage
2V
Maximum High Level Output Current
-24mA
Maximum Supply Voltage
3.6V
Translation
Buffer
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
85°C
Series
MC74LCX541
Height
2.4mm
Length
12.95mm
Standards/Approvals
No
Automotive Standard
AEC-Q100
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
₪ 204.06
₪ 5.37 Each (In a Tube of 38) (ex VAT)
₪ 238.75
₪ 6.283 Each (In a Tube of 38) (inc. VAT)
38
₪ 204.06
₪ 5.37 Each (In a Tube of 38) (ex VAT)
₪ 238.75
₪ 6.283 Each (In a Tube of 38) (inc. VAT)
Stock information temporarily unavailable.
38
| quantity | Unit price | Per Tube |
|---|---|---|
| 38 - 152 | ₪ 5.37 | ₪ 204.06 |
| 190 - 532 | ₪ 3.51 | ₪ 133.38 |
| 570 - 1102 | ₪ 3.495 | ₪ 132.81 |
| 1140 - 2242 | ₪ 2.91 | ₪ 110.58 |
| 2280+ | ₪ 2.745 | ₪ 104.31 |
