Technical Documents
Specifications
Brand
onsemiLogic Family
AC
Product Type
Voltage Level Shifter
Direction Type
Bi-Directional
Maximum Propagation Delay Time @ CL
8ns
Mount Type
Surface
Number of Elements per Chip
1
Package Type
SOIC
Output Type
3 State
Pin Count
20
Logic Function
Buffer
Maximum Low Level Output Current
24mA
Maximum High Level Output Current
-24mA
Minimum Supply Voltage
2V
Maximum Supply Voltage
6V
Translation
Buffer
Minimum Operating Temperature
-40°C
Maximum Operating Temperature
85°C
Length
12.95mm
Standards/Approvals
No
Series
MC74AC540
Height
2.4mm
Automotive Standard
No
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
Stock information temporarily unavailable.
₪ 191.52
₪ 191.52 Each (In a Tube of 38) (ex VAT)
₪ 224.08
₪ 224.08 Each (In a Tube of 38) (inc. VAT)
1
₪ 191.52
₪ 191.52 Each (In a Tube of 38) (ex VAT)
₪ 224.08
₪ 224.08 Each (In a Tube of 38) (inc. VAT)
Stock information temporarily unavailable.
1
| quantity | Unit price |
|---|---|
| 1 - 4 | ₪ 191.52 |
| 5 - 14 | ₪ 125.74 |
| 15 - 29 | ₪ 125.38 |
| 30+ | ₪ 103.88 |
