Microchip MIC5209YM-TR, Linear Voltage Regulator 16V 3-Pin

RS Stock No.: 238-0657Brand: MicrochipManufacturers Part No.: MIC5209YM-TR
brand-logo
View all in Voltage Regulators

Technical documents

Specifications

Brand

Microchip

Product Type

Linear Voltage Regulator

Mount Type

Surface

Polarity

Positive

Quiescent Current

1μA

Pin Count

3

Width

266.7 mm

Length

400.05mm

Series

MIC5209

Height

120.65mm

Standards/Approvals

No

Maximum Operating Temperature

125°C

Maximum Input Voltage

16V

Minimum Input Voltage

2.5V

Automotive Standard

No
