Technical Documents
Specifications
Brand
BroadcomProduct Type
Optocoupler
Mount Type
Surface
Maximum Forward Voltage
1.4V
Number of Channels
4
Packaging
Tape & Reel
Number of Pins
16
Package Type
SO
Input Current Type
DC
Typical Rise Time
2μs
Maximum Input Current
50mA
Isolation Voltage
3750Vrms
Minimum Operating Temperature
-55°C
Maximum Current Transfer Ratio
600%
Maximum Operating Temperature
110°C
Typical Fall Time
3μs
Minimum Current Transfer Ratio
100%
Standards/Approvals
EN, IEC, UL
Series
ACPL
Automotive Standard
AEC-Q100
Stock information temporarily unavailable.
₪ 174.15
₪ 17.415 Each (In a Pack of 10) (ex VAT)
₪ 203.76
₪ 20.376 Each (In a Pack of 10) (inc. VAT)
10
₪ 174.15
₪ 17.415 Each (In a Pack of 10) (ex VAT)
₪ 203.76
₪ 20.376 Each (In a Pack of 10) (inc. VAT)
Stock information temporarily unavailable.
10
| quantity | Unit price | Per Pack |
|---|---|---|
| 10 - 40 | ₪ 17.415 | ₪ 174.15 |
| 50 - 90 | ₪ 11.505 | ₪ 115.05 |
| 100 - 240 | ₪ 10.53 | ₪ 105.30 |
| 250 - 490 | ₪ 9.54 | ₪ 95.40 |
| 500+ | ₪ 8.37 | ₪ 83.70 |
