Wurth, WE-GF, 1812 (4532M) Wire-wound SMD Inductor with a Ferrite Core, 220 μH ±10% Wire-Wound 100mA Idc Q:40
Technical documents
Specifications
Brand
Wurth ElektronikInductance
220 μH
Maximum dc Current
100mA
Package/Case
1812 (4532M)
Length
4.5mm
Depth
3.2mm
Height
3.2mm
Dimensions
4.5 x 3.2 x 3.2mm
Tolerance
±10%
Maximum DC Resistance
10Ω
Series
WE-GF
Core Material
Ferrite
Maximum Self Resonant Frequency
4MHz
Minimum Quality Factor
40
Inductor Construction
Wire-Wound
Maximum Operating Temperature
+105°C
Minimum Operating Temperature
-40°C
Country of Origin
China
Product details
Wurth 1210 WE-GF Series High Frequency Chokes
Wurth WE=GF series high-quality wire wound surface mount inductors for applications such as HF amplifiers, Oscillators, transponders, LC Filter circuits, adapter networks and also HF Circuits such as tuners. Operating temperature -40°c to +105°c.
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
₪ 51.45
₪ 5.145 Each (In a Pack of 10) (ex VAT)
₪ 60.20
₪ 6.02 Each (In a Pack of 10) (inc. VAT)
Standard
10
₪ 51.45
₪ 5.145 Each (In a Pack of 10) (ex VAT)
₪ 60.20
₪ 6.02 Each (In a Pack of 10) (inc. VAT)
Stock information temporarily unavailable.
Standard
10
Stock information temporarily unavailable.
| quantity | Unit price | Per Pack |
|---|---|---|
| 10 - 40 | ₪ 5.145 | ₪ 51.45 |
| 50 - 240 | ₪ 5.025 | ₪ 50.25 |
| 250 - 490 | ₪ 4.905 | ₪ 49.05 |
| 500 - 990 | ₪ 4.56 | ₪ 45.60 |
| 1000+ | ₪ 4.20 | ₪ 42.00 |
