TRACOPOWER TEN 25WI DC-DC Converter, ±12V dc/ ±1.25A Output, 10 → 40 V dc Input, 25W, Through Hole, +85°C Max
Technical documents
Specifications
Brand
TRACOPOWEROutput Voltage
±12V dc
Input Voltage Range
10 → 40 V dc
Power Rating
25 W, 30W
Input Voltage Nominal
24 V dc
Output Current
±1.25A
Mounting Type
Through Hole
Isolated
Yes
Number of Outputs
2
Package
1 x 1.6 in
Isolation Voltage
1.5kV dc
Length
50mm
Depth
9.3mm
Series
TEN 25WI
Load Regulation
±1%
Minimum Temperature
-40°C
Efficiency
89%
Maximum Temperature
+85°C
Country of Origin
Taiwan, Province Of China
Product details
Traco 18W, 25W & 30W Single/Dual Output Regulated Isolated DC-DC Converter - TEN 25WI Series
18W, 25W & 30W Single/Dual output regulated isolated high performance DC-DC converter modules with a wide 4:1 input voltage range. Typical applications for these DC-DC converter modules include industrial electronics, communication systems, battery operated equipment and distributed power systems.
Ultra wide 4:1 input voltage range
Adjustable output voltage
Remote On/Off
Continuous short circuit protection
Over voltage protection
Over temperature protection
I/O isolation 1500 Vdc
Input filter meets EN 55022, class A and FCC, level A without external components
Fully RoHS compliant
Operating temperature range -40 to +85 °C
Ideate. Create. Collaborate
JOIN FOR FREE
No hidden fees!
- Download and use our DesignSpark software for your PCB and 3D Mechanical designs
- View and contribute website content and forums
- Download 3D Models, Schematics and Footprints from more than a million products
Stock information temporarily unavailable.
₪ 558.12
₪ 558.12 Each (ex VAT)
₪ 653.00
₪ 653.00 Each (inc. VAT)
1
₪ 558.12
₪ 558.12 Each (ex VAT)
₪ 653.00
₪ 653.00 Each (inc. VAT)
Stock information temporarily unavailable.
1
| quantity | Unit price |
|---|---|
| 1 - 4 | ₪ 558.12 |
| 5 - 9 | ₪ 550.56 |
| 10 - 24 | ₪ 543.34 |
| 25 - 49 | ₪ 513.62 |
| 50+ | ₪ 487.06 |
