Texas Instruments SN74LVC541APWR Octal-Channel Buffer & Line Driver, 3-State, 20-Pin TSSOP

RS Stock No.: 527-990Brand: Texas InstrumentsManufacturers Part No.: SN74LVC541APWR
brand-logo
View all in Line Interface ICs

Technical documents

Specifications

Brand

Texas Instruments

Logic Family

LVC

Logic Function

Buffer, Line Driver

Number of Channels per Chip

8

Input Type

Single Ended

Output Type

3 State

Polarity

Non-Inverting

Mounting Type

Surface Mount

Package Type

TSSOP

Minimum Operating Temperature

-40 °C

Pin Count

20

Maximum Operating Temperature

+85 °C

Maximum High Level Output Current

-24mA

Maximum Low Level Output Current

24mA

Maximum Propagation Delay Time @ Maximum CL

5.6 ns @ 2.7 V

Dimensions

6.5 x 4.4 x 1.15mm

Height

1.15mm

Maximum Operating Supply Voltage

3.6 V

Minimum Operating Supply Voltage

1.65 V

Propagation Delay Test Condition

50pF

Length

6.5mm

Width

4.4mm

Product details

74LVC Family Inverters & Buffers, Texas Instruments

Texas Instruments range of Inverters and Buffers from the 74LVC Family of Low-voltage CMOS Logic ICs. The 74LVC Family use silicon gate CMOS technology and is designed to operate at 3.3V, allowing a significant reduction in power consumption when compared to 5V systems.

Operating Voltage: 1.65 to 3.6V
5V tolerant inputs
Compatibility: Input LVTTL/TTL, Output LVCMOS
Latch-up performance exceeds 250 mA per JESD 17
ESD protection exceeds JESD 22

74LVC Family
