Technical Documents
Specifications
Brand
SickProduct Type
Photoelectric Sensor
Sensor Style
Rectangular
Detection Type
Through Beam
Output Type
PNP
Terminal Type
3-Pin Connector
Maximum DC Voltage
30V dc
Light Source
LED
Minimum Operating Temperature
-25°C
IP Rating
IP67
Materials Detected
Objects Moving At High Speeds
Maximum Current
100mA
Maximum Operating Temperature
55°C
Standards/Approvals
EN IEC 63000, EU, RL
Response Time
0.25ms
Hazardous Area Certification
EN IEC 63000
Series
W8
Housing Material
Plastic
Mount Type
Threaded, Through Hole
Detection Range
0 → 8 m
Country of Origin
China
