Sensata Crydom Solid State Relay, 4 A rms Load, PCB Mount, 280 V dc Load, 32 V dc Control

RS Stock No.: 353-001Brand: Sensata / CrydomManufacturers Part No.: MP240D4
brand-logo
View all in Solid State Relays

Technical documents

Specifications

Brand

Sensata / Crydom

Maximum Load Current

4 A rms

Mounting Type

PCB Mount

Maximum Load Voltage

280 V dc

Minimum Load Voltage

24 V dc

Minimum Control Voltage

3 V dc

Maximum Control Voltage

32 V dc

Switching Type

Zero Cross

Control Voltage Range

3 → 32 V dc

Minimum Load Current

0.02 A

Terminal Type

PCB Pin

Output Device

Triac

Load Voltage Range

24 → 280V ac

Dimensions

43.1 x 10.2 x 25.4mm

Height

25.4mm

Depth

10.2mm

Length

43.1mm

Operating Temperature Range

-40 → +80°C

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

+80°C

Country of Origin

Mexico

Product details

Series MP 3 - 4A, 240Vac, ac Output SIL

High package density
Compatible with 5, 12 & 24V logic systems
Isolation voltage 4000Vrms
Dimensions: H31.75mm x W10.2mm x D43.1mm
Operating temperature range: -40 to +80°C

Approvals

UL recognised component for Canada and US, VDE
