Nexperia 74HC245D,652, 1 Bus Transceiver, 8-Bit Non-Inverting CMOS, 20-Pin SOIC

RS Stock No.: 113-0174PBrand: NexperiaManufacturers Part No.: 74HC245D,652
brand-logo
View all in Bus Transceivers

Technical documents

Specifications

Brand

Nexperia

Logic Family

HC

Product Type

Bus Transceiver

Logic Function

Bus Transceiver

Number of Channels

8

Polarity

Non-Inverting

Mount Type

Surface

Package Type

SOIC

Minimum Supply Voltage

2V

Pin Count

20

Maximum Supply Voltage

6V

Input Level

CMOS

Minimum Operating Temperature

-40°C

Output Level

CMOS

Maximum High Level Output Current

-7.8mA

Maximum Operating Temperature

125°C

Maximum Low Level Output Current

7.8mA

Width

7.6 mm

Height

2.45mm

Length

13mm

Product details

74HC Family, Nexperia

High-Speed CMOS Logic
Operating Voltage: 2 to 6 V
Compatibility: Input CMOS, Output CMOS

74HC Family
