BEL POWER SOLUTIONS INC Power Supply, FXP1500-48G, 12 V dc, 48 V dc, 1 A dc, 32.2 A dc, 1212 W, 1512 W, Dual Output,
Technical documents
Specifications
Output Voltage
12 V dc, 48 V dc
Output Current
1 A dc, 32.2 A dc
Power Rating
1212 W, 1512 W
Number of Outputs
2
Input Voltage
108 → 264 V ac, 85 → 105 V ac
Length
332.8mm
Width
141.2mm
Depth
40.5mm
Minimum Temperature
0°C
Maximum Temperature
+70°C
Country of Origin
China
Product details
Power-One FXP Series
The Power-One FXP range of power supplies is power-factor-corrected (PFC) and provides a 48 VDC output, and can be used in hot-swap redundant systems. The small dimensions allow configuration of up to three units in a 1U rack.
The highly efficient thermal design with internal-fan cooling permits their use over wide temperature ranges and provides very high reliability. Front panel LEDs, logic signals and an I2C management interface provide status information. In addition, the I2C bus can enable the power supply, set high fan speed, adjust the output voltage, and set the output current limit.
Rear-mounted AC connector
Wide input voltage range
12 V standby voltage, 1 A per front-end
I2C interface status and control
I2C voltage and current limit setting
Overtemperature, output overvoltage, and output overcurrent protection
Status LEDs: AC OK, DC OK, and Fan Fail/Overtemperature Fail
