APEM Toggle Switch, Panel Mount, (On)-Off-(On), DPDT, Solder Lug Terminal, 30 V dc, 125V ac

RS Stock No.: 165-1473Brand: APEMManufacturers Part No.: 5647AB-2
brand-logo
View all in Toggle Switches

Technical documents

Specifications

Brand

Apem

Contact Configuration

DPDT

Switch Operation

(On)-Off-(On)

Contact Current Rating

3 A @ 250 V ac, 4 A @ 30 V dc, 6 A @ 125 V ac

Mounting Type

Panel Mount

Terminal Type

Solder Lug

Illuminated

No

Panel Cut Out Diameter

6.5mm

Actuator Length

17.8mm

Actuator Material

Chrome Plated Brass

Voltage Rating

30 V dc, 125 V ac, 250V ac

Contact Resistance

10mΩ

Panel Cut Out Size

6.5 Dia.mm

Contact Material

Silver

Maximum Operating Temperature

+85°C

Minimum Operating Temperature

-40°C

Standards Met

CECC 96201-007, CSA, cULus Recognised, UL Listed, VDE

Operating Temperature Range

-40 → +85°C

Country of Origin

France
