Alpha Wire Alpha Essentials Communication & Control Series Data Cable, 4 Pairs, 8 Cores, 0.56 mm², Screened, 20 AWG,

RS Stock No.: 187-1986Brand: Alpha WireManufacturers Part No.: 2467C SL005Distrelec Article No.: 30134038
brand-logo
View all in Twisted Pair & Multicore Data Cable

Technical documents

Specifications

Brand

Alpha Wire

Number of Pairs

4

Cross Sectional Area

0.56 mm²

Number of Cores

8

American Wire Gauge

20 AWG

Screened/Unscreened

Screened

Length

30m

Shield Type

Aluminium/Mylar Tape

Sheath Colour

Grey

Cable Type

Control

Outer Diameter

9.22mm

Outer Sheath Material

PVC

Cable Shape

Twisted Pair

Characteristic Impedance

66 Ω

Core Strands

7/28 AWG

Series

Alpha Essentials Communication & Control

Maximum Operating Temperature

+75°C

Voltage Rating

300 V

Shielded/Unshielded

Shielded

Minimum Operating Temperature

-20°C

Standards Met

CSA, UL

View all in Twisted Pair & Multicore Data Cable
