Alpha Wire Alpha Essentials Communication & Control Control Cable, 3 Cores, 2.09 mm², Unscreened, 30m, Grey PVC Sheath,

RS Stock No.: 187-1929Brand: Alpha WireManufacturers Part No.: 1891/3C SL005
brand-logo
View all in Control Cable

Technical documents

Specifications

Brand

Alpha Wire

Series

Alpha Essentials Communication & Control

Number of Cores

3

Cross Sectional Area

2.09 mm²

American Wire Gauge

14 AWG

Conductor Material

Tinned Copper

Sheath Material

PVC

Sheath Colour

Grey

Screened/Unscreened

Unscreened

Minimum Bend Radius

10 x Cable Diameter

Outer Diameter

7.42mm

Length

30m

Voltage Rating

300 V

Maximum Operating Temperature

+80°C

Insulation material

PVC

Conductor Resistance

2.8 Ω

Minimum Operating Temperature

-20°C

Core Strands

41/30 AWG

Stock information temporarily unavailable.

₪ 1,184.85

₪ 39.495 Each (ex VAT)

₪ 1,386.27

₪ 46.209 Each (inc. VAT)

Alpha Wire Alpha Essentials Communication & Control Control Cable, 3 Cores, 2.09 mm², Unscreened, 30m, Grey PVC Sheath,

30

Available in multiples of 30
30₪ 1,184.85
60₪ 2,369.70
90₪ 3,554.55
120₪ 4,739.40
150₪ 5,924.25
180₪ 7,109.10
210₪ 8,293.95
240₪ 9,478.80
270₪ 10,663.65
300₪ 11,848.50
330₪ 13,033.35
360₪ 14,218.20
390₪ 15,403.05
420₪ 16,587.90
450₪ 17,772.75

₪ 1,184.85

₪ 39.495 Each (ex VAT)

₪ 1,386.27

₪ 46.209 Each (inc. VAT)

Alpha Wire Alpha Essentials Communication & Control Control Cable, 3 Cores, 2.09 mm², Unscreened, 30m, Grey PVC Sheath,

Stock information temporarily unavailable.

30

Available in multiples of 30
30₪ 1,184.85
60₪ 2,369.70
90₪ 3,554.55
120₪ 4,739.40
150₪ 5,924.25
180₪ 7,109.10
210₪ 8,293.95
240₪ 9,478.80
270₪ 10,663.65
300₪ 11,848.50
330₪ 13,033.35
360₪ 14,218.20
390₪ 15,403.05
420₪ 16,587.90
450₪ 17,772.75

Technical documents

Specifications

Brand

Alpha Wire

Series

Alpha Essentials Communication & Control

Number of Cores

3

Cross Sectional Area

2.09 mm²

American Wire Gauge

14 AWG

Conductor Material

Tinned Copper

Sheath Material

PVC

Sheath Colour

Grey

Screened/Unscreened

Unscreened

Minimum Bend Radius

10 x Cable Diameter

Outer Diameter

7.42mm

Length

30m

Voltage Rating

300 V

Maximum Operating Temperature

+80°C

Insulation material

PVC

Conductor Resistance

2.8 Ω

Minimum Operating Temperature

-20°C

Core Strands

41/30 AWG
